Hobbywing
QUICRUN WP 1080 G2 brushed ESC (2-3S) for Crawler or RTRs [Hobbywing] 30112750
$49.99
In Stock
Pre-Order
Sold out
SKU: 30112750
SKU: 30112750
Categories: All Products, Electronics, ESCs (Electronic Speed Control)
100% ORIGINAL AND QUALITY
24 MONTHS GUARANTEE
- Description
- Reviews
QUICRUN WP 1080 G2 brushed ESC (2-3S) [Hobbywing] 30112750
Great value esc! Water proof, and perfect for all around brushed cars!
Perfect for CRAWLERS!
Features
Available through the Authorized Dealer Network in North America
Great value esc! Water proof, and perfect for all around brushed cars!
Perfect for CRAWLERS!
Features
- Fully Water-proof and dust-proof, suitable for all-weather races.
- Small in size, with a built-in capacitor module.
- Four operating modes available (Real Car Operating / FWD with Brake / FWD and REV with Brake / FWD and REV)
- In the first "real car mode" The direction of the motor is switchable in real time by using the idle channel on the remote control.
- Real-Time Adjustment of Drag Braking Force.
- 15 programmable parameter items
- PWM Frequency: 1K/2K/4K/8K/16K Adjustable
- Freewheeling (DEO) capability
- Drag brake rate in 9 levels (adjustable)
- Electronic switch
- Aluminum case for great heat dissipation
- Great current endurance capability.
- Great built-in BEC output capacity switchable 6V/ 7.4/ 8.4V
- Automatic throttle range calibration, easy to use.
- Multiple protections:
- Over Voltage Protection
- Low voltage cut-off protection for battery
- Over-heating protection
- Throttle signal loss protection, and much more
- Risk-Free manufacturer's limited warranty available through Authorized Dealers in North America
-
WP-1080 G2 ESC VS WP-1080 (G1)
- BEC output can go up to 8.4V
- Real-Time Adjustment of Drag Braking Force.
- Real Car Mode
- New Aluminum case
| Brushed ESC | WP 1080 G2 | WP 1080 |
WP 1060
|
| p/n | 30120202 | 30112750 | 30120201 |
| Waterproof | Yes | Yes | Yes |
| Dual Mode | No | No | No |
|
Fwd Cont. / Peak
Rev Cont. / Peak
|
80A / 400A | 80A / 400A | 60A / 360A |
| Car Applicable | 1/10 Rock Crawler | 1/8 - 1/10 Rock Crawler and Tank or Boat | 1/10 Touring Car, Buggy, Short Course Truck, Monster, Truggy, Rock Crawler and Tank |
| Motor Limit | Brushed Motors 540/550 Series 2S LiPo or 5S NiMH 3S LiPo or 9S NiMH |
Brushed Motors
540/550/775 Series 2S LiPo or 6S NiMH: ≥10T or\RPM<3000@7.4V 3S LiPo or 9S NiMH: ≥16T or RPM<2000@7.4V |
Brushed motor 540 or 550 series 2S Lipo or 6 NiMH: T ≥12T or RPM<3000 @7.2V 3S Lipo or 9 NiMH: T≥18T or RPM< 2000 @7.2V |
| Battery | 2-3S LiPo or 5-9S NiMH | 2-3S LiPo or 5-9S NiMH | 2-3S Lipo or 5-9 NiMH |
| BEC Output | 6V/7.4V/8.4V @ 4A (switch-mode) | 6V/7.4V @ 3A (switch mode) |
2A/5V (Linear Mode) |
| PWM Frequency | Adjustable 1K/2K/4K/8K/16K |
Adjustable 1K/2K/4K/8K/16K |
1KHz |
| Wires | 14AWG-200mm w/ XT60 Connector | 14AWG-200mm w/ XT60 Connector | 14AWG-200mm w/TAMIYA Connector |
| Size/ Weight | 37.2(L)* 31.9(W)*18.4(H) (without fan) | 36.5(L)* 32(W)*18(H) (without fan) | 36.5(L)*32(W)*18(H) |
| External Program Port | Separate Port Available |
External Program Port Available |
N/A |
| Programming | LED Program card | LED Program card | Jumper Cap |
| Cooling Fan | Without cooling fan | - | |
| Weight* | 70.2g w/ wire and connectors | 58.5g | 39g |
Available through the Authorized Dealer Network in North America
