Actinium V4 10.5T Sensored Brushless Motor 1-10 [Team Powers] TPR-BLM-105100ACT-V4

This is the Team Powers Actinium V4 Competition Sensored Brushless Motor. This motor has built upon the desired features from the Actinium V3.0 motor, such as an improved stator design for better torque at the bottom end. The motor has been given a face lift, with a stealthy black coating on the stator and high grade copper wire for the best motor resistance. The updated and expanded dissipate hole on the convection system helps the motor to run as cool as possible.

Design Specification: Based on IFMAR/ROAR/EFRA/BRCA

Motor Dimensions (Diameter x Length): 35.8mm x 51.5mm

Shaft Diameter: 3.17mm

Magnet Dimensions (Diameter x Length): ~12.5 x7.2x25.2mm (10.5T~21.5T),

Weight: ~150g (vary with different motor turn)

Recommended RC Model Car: 1:10 model car, Buggy, MINI Car
