Futaba

Futaba 10PX 10-Channel 4G Telemetry Radio System w- Receiver R404SBS-E [Futaba] 01004409-1

Name: Futaba 10PX 10-Channel 4G Telemetry Radio System w- Receiver R404SBS-E [Futaba] 01004409-1
Brand: Futaba
SKU: 01004409-1
Price: 799.99 USD
Availability: InStock

$799.99 In Stock Pre-Order Sold out

SKU: 01004409-1

Categories: All Products, Radios

1-4 DAYS DELIVERY

100% ORIGINAL AND QUALITY

24 MONTHS GUARANTEE

Description
Reviews

https://supergdrift.com/product/futaba-ultimate-update-micro-sd-card-preloaded-updates-sbus-microsd-card-4pm-7px-7pxr-10px/

Don't forget your battery!
https://supergdrift.com/product/10px-transmitter-lipo-battery-built-in-usb-c-port-for-pass-thru-charging-t16iz-futaba-4513886309397/
Or a 2400mah REEDY (BEST VALUE) Rechareable LIPO Battery

Futaba 10PX 10-Channel 4G Telemetry Radio System w/ Receiver R404SBS-E [Futaba] 01004409-1

Futaba's high-end car radio system - the 7PX - has been the favourite of many of the world's top drivers. Taking over from the 7PX's DNA, the all new T10PX was born.
With the new F-4G fast response communication system, the incredible response feeling recognized by the world champion has improved!
In addition, telemetry communication - which was not possible with T-FHSS SR protocol, can now be used.
With the new "Feeling" function, the radio can be made to feel like it is custom made to suit each driver.
With support for a full 10 channels, this competition radio is also designed to appear to the scale enthusiast too. The 10PX is Futaba's highest grade on the circuit.
• Lightest in its class & highly balance design
• New high-speed F-4G response system installed
• New response “Feeling” function
• Supports up to 10 channels
• Wide viewing angle full-colour LCD adopted
• New icon menu used
• Can be used as a game controller by using the USB external output terminal
• New wheel unit/APA/APA angle/trigger used
• Throttle and steering spring replacement mechanism
• New shape multi-position rubber grip
• Paddle shift lever switch + bottom switch + 3 position switch incorporated
• Supports left and right-handed specifications
• Large capacity LiFe battery FT2F1100B included
• Optional LiPo battery LT2F2000B can be used
Supplied complete with Futaba R404SBS-E receiver (for use with EP only - not to be used with gas powered models).
Functions / specifications

System menu
Display settings
System information
Voice
Battery settings
Date and time
LED settings
Adjuster
Receiver update
Servo update

Model menu
Model select
Model copy
Model name
Model deletion (in SD card)
Data reset
Model type * New function

Setup menu
Receiver settings
Servo view
Throttle mode
Reverse
Sub trim
Endpoint
Fail-safe function
Acceleration
Trim / dial settings
Switch settings
Condition
Idle up
D/R, ATL
Channel limiter
Channel settings

Racing menu
Curve (EXP) 111
Speed
Traction control
ABS
Start
Engine cut
Feeling * New functionMixing menu
Steering mixing
Brake mixing
Gyro mixing
4WS mixing
Dual ESC
CPS mixing (1.2.3)
Tank mixing
Program mixing (1.2.3.4.5)
Tilt mixing

Telemetry menu
Telemetry system
Telemetry
Sensor list
Sensor menu

Accessory menu
Timer
Wrap list
S.BUS servo
MC (ESC) link
Gyrolink
Index table
Gear ratio table
Home/ES1/ES2/ES3 button settings
Home screen display settings

Specifications
Interface	Colour TFT Touch Screen and Edit Buttons
Mixes	5 Program Mixes
Model Memory	40 (+ SD Card)
ModelName	Up to 15 Characters
Modulation	Futaba F-4G, T-FHSS SR, T-FHSS, S-FHSS, Mini-Z
Receiver	Futaba R404SBS-E Included

FEATURES

-Full color touch screen LCD
T10PX has an HVGA 4.3 inch, full-color, backlit LCD touch screen. The screen is transﬂective which enables both indoor and outdoor visibility.

-F-4G system & telemetry
Equipped with an F-4G system that enables telemetry with faster response than the T-FHSS SR system.

-10 channels
Up to 10 channels can be operated by using the S.BUS2 system together.

-T-FHSS MINIZ system
By setting to the MINIZ system in the receiver setting menu, you can use Kyosho Mini – Z Evo dedicated receiver RA-42. Dedicated receiver RA-42 requires purchase separately.

-Update-able software
Software can be updated by microSD card. Model data can also be saved in a microSD card. In addition, telemetry log data can be saved.

-Model memory for 40 models
Model names can use up to 15 letters, numbers, and symbols, so that logical names may be used. A model memory with different setups can be created by using the model copy function.

-Paddle switch + bottom switch + 3 position switch
A paddle switch near the wheel, a 3-position switch on the grip, and a bottom switch on the bottom are equipped to support multiple channels and functions.

-Lipo battery can be used
The optional LT2F2000B Lipo battery can be used as the transmitter power supply. The running time is extended.

-Brake mixing for large cars
Brake mixing of the front and rear wheels of 1/5GP and other large cars can be adjusted independently.

-Steering mixing
Smooth cornering is possible by the independent left and right steering servo setting.

-4WS mixing for crawlers and other 4WS type
This function can be used with crawlers and other 4-wheel steering type vehicles.

-Dual ESCs mixing for crawlers
ESC at the front and rear are controlled independently.

-Gyro mixing
The sensitivity of Futaba car rate gyros can be adjusted from the T10PX.

-Tank mixing
This function is intended for vehicles such as tanks.

-CPS mixing
LED lighting and ﬂashing control using our CPS-1 channel power switch can be matched to steering and throttle operation by switch only.

-S.BUS servo
This is a special function that allows setting of the parameters of our S.BUS servo whose settings are changed by using PC Link software.

-MC-Link
This is a dedicated function which allows setting of the contents of the Link software which makes possible Futaba speed controller (ESC), MC960CR, MC950CR,MC850C, MC851C, MC602C, MC402CR, etc. variable frequency and other data changes by PC at the T10PX.

-Throttle speed
Sudden trigger operation on a slippery road surface will only cause the tires to spin and the model to not accelerate smoothly. By setting the throttle speed function, operation can be performed smoothly and easily.It also suppresses battery consumption.

-Steering speed
When you sense that the steering servo is too fast, etc.,the servo operating speed (direction that suppresses the maximum speed) can be adjusted.

-Non-telemetry LED
When the telemetry function is OFF to conﬁrm that the telemetry function is not operating.

-Dial select function
This function assigns functions to dials (digital trim,grip dial, knob). The step amount and operating direction can also be adjusted. Trim positioning at each model call is unnecessary because all the dials are digital.

-Switch select function
This function assigns functions to 10 switches. The operating direction can also be set.

-Wheel & Trigger position can be changed
The wheel position can be oﬀset by using an accessory APA wheel position oﬀset adapter.
The wheel angle can also be adjusted.The position of the throttle trigger can be moved for-
ward and backward.

-Rubber Grip
It is possible to convert to a narrow grip type by ex-changing the rubber grip.

-Trim/dial lock functions
Lock functions which prohibit setting and operation by transmitter trim, and dials are provided.

-Left-handed support
The left and right installation direction of the wheel section can be reversed.

-Vibrator built into the grip
The vibrator can be operated at racing timer lap navigation, time-up, and low battery, telemetry alarm.

-USB port
The transmitter can be used as a game controller by connecting it to a computer with a USB cable. (Some games cannot be used.)

YOUR T10PX INCLUDES THE FOLLOWING COMPONENTS:

T10PX Transmitter
R404SBS OR R404SBS-E Receiver
Dry Battery Holder
Wheel offset adapter two size (APA)APA Mounting screws *Spare screws are also included
Wheel adapter 32 deg
Wheel Angle spacer 5 deg
Large diameter steering wheel
Trigger guard (Lx1/Rx1)
Grip rubber x1
Blind paddle x2
Hex wrench
Short manual

TRANSMITTER SPECS

WHEEL SYSTEM, 10 CHANNELS (F-4G SYSTEM), 4 CHANNELS WITH TFHSS-SR, T-FHSS SYSTEM

TRANSMITTING FREQUENCIES:
2.4 GHz band/ -Transmitting RF power output: 100 mW EIRP
PROTOCOLS:
T-FHSS-SR/T-FHSS/S-FHSS/F-4G
POWER REQUIREMENT:
LiPo – NLF2F2000B (7.4 V)
LiFe – FT2F1700BV2 (6.6 V)
CURRENT DRAIN:
350 mA or less (When the T-FHSS, Vibration off, back lighting on)
TRANSMITTING ANTENNA:
1/2λ dipole
4.3 INCH BACKLIT COLOR TFT LIQUID CRYSTAL TOUCH PANEL*
*When you turn on your 10PX, bright dots may appear on your screen display. Your display contains an extremely large number of TFT and is manufactured using high-precision technology. Any bright dots that may appear on your display are intrinsic of the TFT manufacturing technology.

RECEIVER SPECS

R404SBS

F-4G

SIZE:
1.00×0.81×0.42 inch
25.5×20.7×10.6 mm
WEIGHT:
5.7 g
0.2 oz
OPERATING VOLTAGE:
DC 3.7-7.4V

R404SBS-E

F-4G

SIZE:
1.00×0.81×0.42 inch
25.5×20.7×10.6 mm
WEIGHT:
5.7 g
0.2 oz
OPERATING VOLTAGE:
DC 3.7-7.4V
