Hobbywing
XeRun XD10 PRO ESC DRIFT (2S) ESC Speed Controller (Boost and Turbo) XD 10 [Hobbywing] 30112614 30112615 30112616
$157.99
In Stock
Pre-Order
Sold out
SKU: 30112615
SKU: 30112615
Categories: All Products, ESCs (Electronic Speed Control)
100% ORIGINAL AND QUALITY
24 MONTHS GUARANTEE
- Description
- Reviews
Features:
- Built-in switch mode BEC with a maximum output of 10A and voltage adjustable from 5V to 7.4V (step: 0.1V) for usage with servos & other devices require different voltages.
- A separate PRG/FAN port is able to power an external fan to maximize cooling performance or connect an LCD program box or WiFi module to the ESC.
- Variable frequency regulation of PWM & brake frequencies allows users to precisely regulate the driving & braking forces (of the motors).
- Multiple protections: low-voltage cutoff protection, ESC and motor thermal protection, and fail-safe (throttle signal loss protection), reverse polarity protection (the external standard cap pack will still be damaged if battery reversal occurs).
- Data logging for recording the maximum ESC/motor temperature, motor speed/RPM, and others in real-time.
- Firmware upgrade via Hobbywing multifunction LCD program box or OTA Programmer (item sold separately)
Specifications
| ID | Xerun XD10 PRO ESC - Drift |
| P/N |
30112614 Stealth
30112615 Passion 30112616 Purple |
| Application | 1/10th drift car |
| Cont./Peak Current | 100A/800A |
| Input Voltage | 2S LiPo/4-6S NiMH |
| BEC Output | 5-7.4V Adjustable, Continuous Current of 5A (Switch-mode) |
| Wires & Connectors | Standard: 13AWG 200mm |
| Programming device | LCD program box OTA programmer (available through Firmware update) |
| Firmware | LCD Program box via USB software (PC only) OTA (iOS / Android) |
| Size & Weight | 40.7x35.0x32.0mm (w/Fan) |
| Weight | 95g (w/ wires) |
| Motor Limit* | Brushless Motor Limit with 2S LiPo/6S NiMH: 8.5T |
Contents:
- XD10 PRO ESC w/ a cooling fan
- (2) Input wires & (3) Output wires -PRE-SOLDERED-
- (2) x cooling fan (comes with one backup fan)
- Decals
- Bonus parts: heat tubes, double tape, nylon cable zap traps
